EN837-3德国wika膜盒压力表微压压力表632.50

发布日期：2018-06-01　浏览次数：413

EN837-3德国wika膜盒压力表进口微压压力表632.50

632.50威卡膜盒压力表主要应用

带可充液外壳，可用于具有高动态压力脉冲或振动的应用场合

适用于干燥的侵蚀性气体介质以及侵蚀性环境中

过程工业：化工、石化、制药、生物技术、机械和发电工业

632.50主要参数

符合EN 837-3标准

标准尺寸 (mm)：63、100和160

准确度等级：1.6

量程

NS 63：0 ... 4 kPa至0 ... 60 kPa

NS 100：0 ... 1.6 kPa至0 ... 60 kPa

NS 160：0 ... 0.25 kPa至0 ... 60 kPa

或所有其他同等负压量程或正压和负压联程
632.50膜盒压力表常用量程接口

632.50.063 0 bar...0,25 bar 1/4 NPT lower mount

632.50.063 0 in.WC...60 in.WC 1/4 NPT lower mount

632.50.063 0 kPa...25 kPa G1/4B lower mount

632.50.063 0 mbar...100 mbar G1/4B lower mount

632.50.063 -100 mbar...0 mbar G1/4B center back mount

632.50.063 -60 mbar...0 mbar 1/4 NPT lower mount

632.50.100 0 in.WC...100 in.WC 1/2 NPT lower mount

632.50.100 0 kPa...10 kPa 1/2 NPT lower mount

632.50.100 0 kPa...20 kPa 1/2 NPT lower mount

632.50.100 0 kPa...25 kPa G1/2B lower back mount

632.50.100 0 kPa...25 kPa M20 x 1.5 lower mount

632.50.100 0 kPa...30 kPa M20 x 1.5 lower mount

632.50.100 0 kPa...40 kPa M20 x 1.5 lower mount

632.50.100 0 mbar...100 mbar G1/2B lower mount

632.50.100 0 mbar...250 mbar 1/2 NPT lower mount

632.50.100 0 mbar...40 mbar G1/2B lower mount

632.50.100 0.04 Mpa 1/2 NPT lower mount

632.50.100 -0.5~1.1KPa M20 x 1.5 lower mount

632.50.100 -1.5....+1.5KPa 1/2 NPT lower mount

632.50.100 -15kpa...15kpa 1/2 NPT lower mount

632.50.100 -16 kPa...0 kPa G1/2B lower mount

632.50.100 -25 kPa...0 kPa G1/2B lower mount

632.50.100 -50 mbar...50 mbar G1/2B lower mount

632.50.160 0 kPa...10 kPa 1/2 NPT lower mount

632.50.160 0 kPa...40 kPa 1/2 NPT lower mount

632.50.160 0 kPa...6 kPa 1/2 NPT lower mount

632.50.160 0 mbar...250 mbar 1/2 NPT lower mount

632.50.160 0 mbar...50 mbar 1/2 NPT lower mount

632.50.160 0 mbar...60 mbar 1/2 NPT lower mount

632.50.160 -1,5 kPa...2,5 kPa 1/2 NPT lower mount

632.50.160 -125 Pa...125 Pa M20 x 1.5 lower mount

632.50.160 -40 kPa/40 kPa M20 x 1.5 lower mount

632.50.160 -6 kPa...10 kPa 1/2 NPT lower mount

633.50.100 0 kPa...10 kPa 1/2 NPT lower mount

633.50.100 0 kPa...25 kPa 1/2 NPT lower mount

633.50.100 0 kPa...25 kPa M20 x 1.5 lower mount

633.50.100 0 kPa...40 kPa 1/2 NPT lower mount

633.50.100 -10 kPa...0 kPa G1/2B lower back mount

633.50.100 -600 mbar...0 mbar G1/2B lower back mount

633.50.160 0 kPa...25 kPa 1/2 NPT lower mount

633.50.160 0 mbar...200 mbar G1/2B lower mount

633.50.160 0 mbar...500 mbar 1/2 NPT lower mount
633.50

633.50
