德威尔浮子液位控制器L6EPB-B-S-3-C Dwyer

发布日期：2018-03-30　浏览次数：656

德威尔浮子液位控制器L6EPB-B-S-3-C Dwyer

L6浮子液位控制器选型表

EXAMPLE	L6	EP	BB	D	3	O	CSA	B0HB	Series L6EPB-B-D-3-O-CSA-B0HB Flotect® Liquid Level Switch, brass body, DPDT, spherical polypropylene float, side wall mount, CSA approval, with 1-1/2" hex type brass bushing.
SERIES	L6								Flotect® Liquid Level Switch
CONSTRUCTION		EP							Explosion Proof
BODY			BB SS						Brass Stainless Steel
SWITCH TYPE				D S					DPDT SPDT
LINE SIZE					3 4				1" 1" BSPT
FLOAT TYPE & INSTALLATION						O A B C H L S			Spherical Polypropylene, Side Wall Mount Cylindrical 304SS, Side Wall Mount Spherical Polypropylene, Brass External Float Chamber Spherical 304SS, Side Wall Mount Spherical 304SS, Brass External Float Chamber Spherical 304SS, 304SS External Float Chamber Spherical Polypropylene, 304SS External Float Chamber
OPTIONS							AT CSA GL IEC KC MT MV ST TBC TOP		ATEX Approval CSA Approval Ground Leads IECEx Approval Korean Certified High Temperature Gold Contacts Stainless Steel Tag Terminal Block Connector Top Mounted Float
BUSHINGS/ TEES & BUSHINGS								B0HB B0H4 B1HB B1H4 B0HBE B0H4E B1HBE B1H4E TB2BS TB2S TB2B2E TB2SE	1-1/2" Hex Type Brass Bushing 1-1/2" Hex Type 304SS Bushing 2" Hex Type Brass Bushing 2" Hex Type 304SS Bushing 1-1/2" BSPT Hex Brass 1-1/2" BSPT Hex 304 SST 2" BSPT Hex Brass 2" BSPT Hex 304 SST 2" Brass 250# Tee & Bushing 2" 316SS Tee & Bushing 2" BSPT Brass 250# Tee & Bushing 2" BSPT 316 SST Tee & Bushing
